Simplify and accelerate your automated processes with Balluff's versatile color sensors. For recognition of color nuances in textiles, for example, of painted sheets as well as with colored markings on packaging or labels. Our color sensors sort out bad components and thus assure uniformly high product quality. In this manner, they contribute to a reliable production process.
Key features
Series
26K
Dimension
17 x 50 x 50 mm
Interface
3x PNP Normally open (NO)
Input function
Emitter on/off, Key disable on/off, Teach color (switchpoint)
Principle of operation
Color sensor
Principle of optical operation
Diffuse sensor, Fixed focus
Beam characteristic
Focused
Light type
White light
Light spot size
Ø 4 mm at 22 mm
Range
12...32 mm
Connection
Connector, M12x1-Male, 8-pin
Housing material
ABS
Material sensing surface
PMMA
Operating voltage Ub
12...28 VDC
Approval/Conformity
CE, cULus, EAC, WEEE
